Image title:

[Festiniog Railway Locomotive]

Taken from

Status:

Out of copyright (called public domain in the USA), hence royalty-free stock image for all purposes usage credit requested
Please do not redistribute without permission, since running this site is expensive.

Notes:

In the example here given, the engine is on two trucks [bogies]. The one end can be turned so that the double sets of wheels are not in the same straight line. In practice it is found that bogie carriages bring a great strain on curves. In the “Little Wonder,” which works on the Festiniog Railway [in Wales], constructed to a gauge of 1 ft. 11½ in., or the two foot gauge, the boiler is double, with two fire boxes, two barrels and two sets of tubes, and two chimneys. A bogie or swivelling truck is placed under each barrel, and each bogie has two pairs of wheels coupled together, working independently by a pair of steam cylinders to each.” (p. 243)

Keywords:

Dimensions:

127 x 38mm (5.0 x 1.5 inches)
