Figs. 15 and 16.—Showing Siemens’ Alternate Current Dynamo, with its Excitor.details

[Picture: Figs. 15 and 16.—Showing Siemens’ Alternate Current Dynamo, with its Excitor.]
previous image
up

Image title:

Figs. 15 and 16.—Showing Siemens’ Alternate Current Dynamo, with its Excitor.

Source:

Keywords:

Status:

out of copyright (called public domain in the USA), hence royalty-free stock image for all purposes usage credit requested
Please do not redistribute without permission, since running this site is expensive.

Notes:

Fig. 15 shows the only form of alternator that has been used on board ship [as of 1892]. It is of the Siemens pattern; having, as already explained, a double crown of short field-magnets with the starlike armature revolving in the space between them.

Fig. 16 shows the excitor, as it is termed, that is used with this dynamo. It is a series wound Siemens’ dynamo of the early type.

The initials W.M.R.Q. on the engraving could be the engraver’s initials, the artist’s initials, or both.
