The Mode in which Antient Castles were generally built. 1 The Barbacan.
2 The Ditch or Moat.
3 Wall of the outer Ballium.
4 Outer Ballium.
5 Artificial Mount.
6 Wall of the inner Ballium.
7 Inner Ballium.
8 Keep or Dunjeon.
Published according to the Act of Parliament, by Alexr. Hogg, No. 16 Paternoster Row.
There is also a version of this image without the caption.
